Designed for Diameters φ4–10mm.
The HL-T-107 solves these industrial bottlenecks by automating the folding and compression process, transforming a messy manual task into a high-precision, high-speed operation (up to 1,200 pcs/h) suitable for electronics, medical, and consumer goods.
Mechanical arms automatically close and compress labels upon sensor detection.
Physically locks the cylindrical object in the center of the folding zone.
Integrates heavy-duty components within a small 650mm x 800mm footprint.
The operator places the cable or product into the customized fixture.
High-precision sensors detect the material and trigger the servo-dispenser.
The mechanical mechanism closes to wrap the label precisely around the object.
The machine compresses the fold to ensure a bubble-free, permanent bond.
| Category | Attribute | Value |
|---|---|---|
| Performance | Production Speed | 1,000 – 1,200 pcs/h (Varies by operator speed) |
| Precision | Labeling Accuracy | ±0.5 – 1 mm |
| Compatibility | Product Diameter Range | φ4 mm – φ10 mm (Customizable for larger sizes) |
| Label Specs | Fold-over Label Width | 40 mm – 130 mm |
| Label Length Range | 10 mm – 45 mm | |
| Hardware | Control System | Industrial PLC (Siemens or Mitsubishi) |
| Driving System | High-precision Servo-driven Labeling Heads | |
| Physicals | Machine Size | 650 * 800 * 1,100 mm |
| Machine Weight | 80 kg | |
| Power | Electricity Supply | 220V / 50Hz (Power: 0.25 kW) |
Industrial wire harnesses, USB data cables, and power cords requiring flag-type identification labels.
Precise wrap-around and folding labels for paint pens, eyebrow pencils, and markers.
Identification for lollipops, jelly sticks, clothes hangers, and cutlery handles.
Specialized fixtures for irregular handle shapes or non-standard wire diameters.
Adjustments for ultra-wide or ultra-short label specifications.
Standard mechanical setup is optimized for φ4mm – φ10mm; products outside this range require custom engineering.
As a semi-automated feeding system, the final output speed is dependent on the manual loading rhythm of the operator.
To maintain precision, fixtures should be kept clean of any adhesive buildup from label rolls.
"Stop sticking labels by hand. Achieve professional alignment every time."
Get the "Blue Ocean" advantage for your cable or stationery brand.
Contact us to receive:
Send us your wire or product samples, and I will record a macro video of the HL-T-107 performing the fold on your specific materials.
Our engineers will design the physical layout for your specific diameter requirements.
Factory-direct pricing for the most reliable flag-labeler in its class.
✔ Response within 12 hours
✔ Free sample testing available
✔ Custom solution & quotation
